TPS61120RSARG4
RoHS
RoHS compliant
RoHS compliantPackage 16-VQFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Power Management - Specialized
Description
TPS61120 Tape & Reel (TR) Surface Mount Handheld/Mobile Devices pmic power management device 4mm 5.5V 600kHz -40C~85C
PDF
/
Buying Options
Total Price: USD $2.82
Unit Price: USD $2.8177
≥1 USD $2.8177
≥10 USD $2.31135
≥100 USD $2.23915
≥500 USD $2.16695
≥1000 USD $2.09475
Inventory: 1155
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 900μm
Width 4mm
Length 4mm
Height 1mm
Technical
Switching Frequency 600kHz
Control Technique PULSE WIDTH MODULATION
Max Input Voltage 5.5V
Control Mode CURRENT-MODE
Min Input Voltage 1.8V
Topology Boost
Quiescent Current 40μA
Output Current 500mA
Operating Supply Current 10μA
Analog IC - Other Type BATTERY CHARGE CONTROLLER
Input Voltage-Nom 3.3V
Operating Supply Voltage 5.5V
Output Type Adjustable
Output Voltage 5.5V
Efficiency 95 %
Number of Outputs 2
Pin Count 16
Base Part Number TPS61120
Terminal Pitch 0.65mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position QUAD
Voltage - Supply 1.8V~5.5V
Subcategory Switching Regulator or Controllers
Applications Handheld/Mobile Devices
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Weight 41.503702mg
Number of Pins 16
Package / Case 16-VQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 days ago)
Factory Lead Time 6 Weeks
Alternative Model
