TPS2514AQDBVRQ1
RoHS
RoHS compliant
RoHS compliantPackage SOT-23-6
Category Integrated Circuits (ICs) / PMIC - Power Management - Specialized
Description
TPS2514 Tape & Reel (TR) Surface Mount USB Dedicated Charging Port (DCP) Power Switch pmic power management device 2.9mm 5V -40C~125C 155muA
PDF
/
Buying Options
Total Price: USD $1.24
Unit Price: USD $1.2445
≥1 USD $1.2445
≥10 USD $1.02125
≥100 USD $0.9899
≥500 USD $0.9576
≥1000 USD $0.9253
Inventory: 1125
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Thickness 1.2mm
Width 1.6mm
Length 2.9mm
Height 1.45mm
Technical
Supply Current-Max (Isup) 0.22mA
Adjustable Threshold NO
Output Current 35mA
Operating Supply Current 155μA
Analog IC - Other Type POWER SUPPLY SUPPORT CIRCUIT
Number of Channels 1
Supply Voltage-Min (Vsup) 4.5V
Supply Voltage-Max (Vsup) 5.5V
Number of Outputs 1
Base Part Number TPS2514
Terminal Pitch 0.95mm
Supply Voltage 5V
Number of Functions 1
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Applications USB Dedicated Charging Port (DCP), Power Switch
Terminal Finish Matte Tin (Sn)
Resistance 200Ohm
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series Automotive, AEC-Q100
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Weight 36.003894mg
Number of Pins 6
Package / Case SOT-23-6
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Copper
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 6 Weeks
