MAX1823EUB+
RoHS
RoHS compliant
RoHS compliantPackage 10-TFSOP, 10-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / PMIC - Power Management - Specialized
Description
Tube Surface Mount USB Peripherals BICMOS pmic power management device 3mm 5V -40C~85C 50muA
PDF
/
Buying Options
Total Price: USD $2.11
Unit Price: USD $2.11375
≥1 USD $2.11375
≥10 USD $1.7347
≥100 USD $1.68055
≥500 USD $1.6264
≥1000 USD $1.57225
Inventory: 39408
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3mm
Length 3mm
Height Seated (Max) 1.1mm
Technical
Current - Supply 50μA
Adjustable Threshold NO
Analog IC - Other Type POWER SUPPLY SUPPORT CIRCUIT
Number of Channels 1
Supply Voltage-Min (Vsup) 4V
Supply Voltage-Max (Vsup) 5.5V
JESD-30 Code S-PDSO-G10
Pin Count 10
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code unknown
Terminal Pitch 0.5mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4V~5.5V
Technology BICMOS
Applications USB, Peripherals
Terminal Finish MATTE TIN
Number of Terminations 10
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e3
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Surface Mount YES
Package / Case 10-TFSOP, 10-MSOP (0.118, 3.00mm Width)
Mounting Type Surface Mount
