FAN7316M
RoHS
/
Package 20-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / PMIC - Power Management - Specialized
Description
RoHS Compliant LCD TV/Monitor Surface Mount Tube LCD TV/Monitor 1.4W 2mA -25C~85C 312kHz
PDF
/
Buying Options
Total Price: USD $0.99
Unit Price: USD $0.9856
≥1 USD $0.9856
Inventory: 1173
Minimum: 1
-
+
Technical Details
Technical
Max Supply Voltage 22V
Min Supply Voltage 4.5V
Nominal Supply Current 2mA
Power Dissipation 1.4W
Max Supply Current 2mA
Max Frequency 312kHz
Base Part Number FAN7316
Frequency 312kHz
Voltage - Supply 4.5V~24V
Max Power Dissipation 1.4W
Applications LCD TV/Monitor
Min Operating Temperature -25°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Packaging Tube
Operating Temperature -25°C~85°C
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Physical
Supplier Device Package 20-SOIC
Number of Pins 20
Package / Case 20-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
