LTC3553EUD#TRPBF image
Favorite
LTC3553EUD#TRPBF image
Favorite
RoHS
RoHS RoHS compliant
Package 20-WQFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Power Management - Specialized
Description LTC3553 Tape & Reel (TR) Surface Mount Handheld/Mobile Devices pmic power management device 3mm 5.5V -40C~85C 12muA
PDF
/
Buying Options
Total Price: USD $5.76
Unit Price: USD $5.7552
≥1 USD $5.7552
≥10 USD $5.19728
≥100 USD $4.955808
≥500 USD $4.3032
≥1000 USD $4.109811
≥3000 USD $3.747181
Inventory: 1361
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Dimensions

Length 3mm
Height Seated (Max) 0.8mm

Technical

Number of Cells 1
Supply Current-Max (Isup) 500mA
Max Input Voltage 5.5V
Min Input Voltage 4.35V
Adjustable Threshold YES
Operating Supply Current 12μA
Analog IC - Other Type POWER SUPPLY SUPPORT CIRCUIT
Number of Channels 1
Power Supplies 5V
Qualification Status Not Qualified
Number of Outputs 2
Pin Count 20
Base Part Number LTC3553
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.4mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form NO LEAD
Terminal Position QUAD
Voltage - Supply 4.3V~5.5V
Technology CMOS
Subcategory Power Management Circuits
Applications Handheld/Mobile Devices
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2012
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C

Physical

Number of Pins 20
Surface Mount YES
Package / Case 20-WQFN Exposed Pad
Mounting Type Surface Mount

Supply Chain

Lifecycle Status PRODUCTION (Last Updated: 3 weeks ago)
Factory Lead Time 8 Weeks
