LTC3553EUD-2#TRPBF
RoHS
RoHS compliant
RoHS compliantPackage 20-WFQFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Power Management - Specialized
Description
LTC3553 Tape & Reel (TR) Surface Mount Handheld/Mobile Devices pmic power management device 3mm 5V -40C~85C 12muA
PDF
/
Buying Options
Total Price: USD $4.52
Unit Price: USD $4.518378
≥1 USD $4.518378
≥10 USD $4.262619
≥100 USD $4.021337
≥500 USD $3.793714
≥1000 USD $3.578977
Inventory: 1199
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3mm
Length 3mm
Height Seated (Max) 0.8mm
Technical
Supply Current-Max (Isup) 500mA
Current - Supply 12μA
Adjustable Threshold YES
Analog IC - Other Type POWER SUPPLY SUPPORT CIRCUIT
Number of Channels 1
Supply Voltage-Min (Vsup) 4.35V
Power Supplies 5V
Supply Voltage-Max (Vsup) 5.5V
Qualification Status Not Qualified
JESD-30 Code S-PQCC-N20
Pin Count 20
Base Part Number LTC3553
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.4mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form NO LEAD
Terminal Position QUAD
Voltage - Supply 4.35V~5.5V
Technology CMOS
Subcategory Power Management Circuits
HTS Code 8542.39.00.01
Applications Handheld/Mobile Devices
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series PowerPath?
Published 2012
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Surface Mount YES
Package / Case 20-WFQFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
