LTC3109IGN#TRPBF
RoHS
RoHS compliant
RoHS compliantPackage 20-SSOP (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Power Management - Specialized
Description
Not Qualified ROHS3Compliant HYSTERETIC CURRENT MODE 8542.39.00.01 Energy Harvesting 6mA -40C~125C 0.5V 8.649mm
PDF
/
Inventory: 4816
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 20
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Applications Energy Harvesting
Additional Feature ALSO OPERATES AS LDO REGULATOR
HTS Code 8542.39.00.01
Subcategory Power Management Circuits
Technology CMOS
Voltage - Supply 30mV~500mV
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 0.635mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number LTC3109
Pin Count 20
JESD-30 Code R-PDSO-G20
Qualification Status Not Qualified
Output Voltage 5V
Power Supplies 5V
Analog IC - Other Type SWITCHING REGULATOR
Current - Supply 6mA
Input Voltage (Min) 0.05V
Control Mode CURRENT-MODE
Output Current-Max 0.026A
Input Voltage (Max) 0.5V
Control Technique HYSTERETIC CURRENT MODE
Switcher Configuration BOOST
Part Status Active
JESD-609 Code e3
Published 2013
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Dimensions
Height Seated (Max) 1.75mm
Length 8.649mm
Width 3.899mm
Physical
Surface Mount YES
Package / Case 20-SSOP (0.154, 3.90mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
Compliance
RoHS Status ROHS3 Compliant
