TPS27S100BRRKR
RoHS
RoHS compliant
RoHS compliantPackage 16-WFQFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Power Distribution Switches, Load Drivers
Description
Tape & Reel (TR) TPS27S100 Over Load Over Temperature Short Circuit UVLO SINK power distribution switch 5V 50μs 13A 80m Ohm
PDF
/
Buying Options
Total Price: USD $2.25
Unit Price: USD $2.2528
≥1 USD $2.2528
≥10 USD $2.02576
≥100 USD $1.911008
≥500 USD $1.628088
≥1000 USD $1.528736
≥3000 USD $1.337635
Inventory: 9670
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Output Current Flow Direction SINK
Built-in Protections TRANSIENT; OVER CURRENT; THERMAL; UNDER VOLTAGE
Turn Off Time 50 μs
Rds On (Typ) 80m Ω
Turn On Time 80 μs
Fault Protection Over Load, Over Temperature, Short Circuit, UVLO
Voltage - Load 4V~40V
Ratio - Input:Output 1:1
Switch Type Relay, Solenoid Driver
Input Type Non-Inverting
Voltage - Supply (Vcc/Vdd) Not Required
Output Configuration High Side
Current - Output (Max) 13A
Interface Logic
Supply Voltage-Min (Vsup) 5V
Supply Voltage-Max (Vsup) 40V
Output Type N-Channel
Number of Outputs 1
Base Part Number TPS27S100
Supply Voltage 24V
Number of Functions 1
Terminal Form NO LEAD
Terminal Position QUAD
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Terminations 16
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
Feature Shutdown
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TJ
Physical
Surface Mount YES
Package / Case 16-WFQFN Exposed Pad
