TPS2228DB
RoHS
RoHS compliant
RoHS compliantPackage 30-SSOP (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / PMIC - Power Distribution Switches, Load Drivers
Description
GULL WING ROHS3Compliant Obsolete Lead Free PCMCIA Switch Power Switch/Driver -40C~85C TA 97m Ohm 30.67mW 1A
PDF
/
Buying Options
Total Price: USD $4.22
Unit Price: USD $4.21515
≥1 USD $4.21515
≥10 USD $3.458
≥100 USD $3.35065
≥500 USD $3.24235
≥1000 USD $3.13405
Inventory: 7003
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 5.3mm
Technical
Rds On (Typ) 97m Ω
Fault Protection Current Limiting (Fixed), Over Temperature
Voltage - Load 1.8V 3.3V 5V
Ratio - Input:Output 3:4
Nominal Input Voltage 5.5V
Switch Type PCMCIA Switch
Adjustable Threshold YES
Voltage - Supply (Vcc/Vdd) Not Required
Power Dissipation 30.67mW
Output Configuration High Side
Nominal Supply Current 95μA
Number of Ports 2
Analog IC - Other Type POWER SUPPLY SUPPORT CIRCUIT
Interface Serial
Number of Channels 3
Supply Voltage-Min (Vsup) 3V
Power Supplies 1.83.35V
Supply Voltage-Max (Vsup) 3.6V
Max Output Current 1A
Number of Outputs 4
Pin Count 30
Base Part Number TPS2228
Terminal Pitch 0.65mm
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Subcategory Power Management Circuits
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Resistance 72mOhm
ECCN Code EAR99
Number of Terminations 30
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Status Flag
JESD-609 Code e4
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Weight 217.61094mg
Number of Pins 30
Surface Mount YES
Package / Case 30-SSOP (0.209, 5.30mm Width)
Mounting Type Surface Mount
