TPS2224DB
RoHS
RoHS compliant
RoHS compliantPackage 24-SSOP (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / PMIC - Power Distribution Switches, Load Drivers
Description
Tube TPS2224 Current Limiting (Fixed) Over Temperature e4 power distribution switch 8.2mm 3V 1A 95m Ohm
PDF
/
Buying Options
Total Price: USD $2.15
Unit Price: USD $2.147
≥1 USD $2.147
≥10 USD $1.76225
≥30 USD $1.70715
≥100 USD $1.65205
Inventory: 1187
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 6 days ago)
Physical
Mounting Type Surface Mount
Package / Case 24-SSOP (0.209, 5.30mm Width)
Surface Mount YES
Number of Pins 24
Weight 172.39345mg
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
JESD-609 Code e4
Feature Status Flag
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 24
ECCN Code EAR99
Resistance 85mOhm
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Additional Feature BREAK-BEFORE-MAKE SWITCHING
Subcategory Power Management Circuits
Technology BICMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3.3V
Terminal Pitch 0.65mm
Base Part Number TPS2224
Pin Count 24
Number of Outputs 4
Max Output Current 1A
Supply Voltage-Max (Vsup) 3.6V
Supply Voltage-Min (Vsup) 3V
Number of Channels 3
Interface Serial
Analog IC - Other Type POWER SUPPLY SUPPORT CIRCUIT
Number of Ports 2
Output Configuration High Side
Voltage - Supply (Vcc/Vdd) Not Required
Adjustable Threshold NO
Switch Type PCMCIA Switch
Nominal Input Voltage 13.5V
Ratio - Input:Output 3:4
Voltage - Load 3.3V 5V 12V
Min Current Limit 1A
Fault Protection Current Limiting (Fixed), Over Temperature
Rds On (Typ) 95m Ω
Dimensions
Height 2mm
Length 8.2mm
Width 5.3mm
Thickness 1.95mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
