TPS2223PWP
RoHS
RoHS compliant
RoHS compliantPackage 24-TSSOP (0.173, 4.40mm Width) Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Power Distribution Switches, Load Drivers
Description
GULL WING ROHS3Compliant Obsolete Lead Free PCMCIA Switch Power Switch/Driver -40C~85C TA 95m Ohm 3.322W 1A
PDF
/
Buying Options
Total Price: USD $3.32
Unit Price: USD $3.320842
≥1 USD $3.320842
≥10 USD $3.132871
≥100 USD $2.955536
≥500 USD $2.788241
≥1000 USD $2.630413
Inventory: 995
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 24-TSSOP (0.173, 4.40mm Width) Exposed Pad
Number of Pins 24
Weight 98.08935mg
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
JESD-609 Code e4
Feature Status Flag
Part Status Obsolete
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 24
ECCN Code EAR99
Resistance 85mOhm
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Additional Feature BREAK-BEFORE-MAKE SWITCHING
Subcategory Power Management Circuits
Technology BICMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3.3V
Terminal Pitch 0.65mm
Base Part Number TPS2223
Pin Count 24
Number of Outputs 4
Max Output Current 1A
Supply Voltage-Max (Vsup) 3.6V
Power Supplies 3.35V
Supply Voltage-Min (Vsup) 3V
Number of Channels 3
Interface Serial
Analog IC - Other Type POWER SUPPLY SUPPORT CIRCUIT
Number of Ports 2
Nominal Supply Current 140μA
Output Configuration High Side
Power Dissipation 3.322W
Voltage - Supply (Vcc/Vdd) Not Required
Adjustable Threshold NO
Switch Type PCMCIA Switch
Nominal Input Voltage 13.5V
Ratio - Input:Output 3:4
Voltage - Load 3.3V 5V
Fault Protection Current Limiting (Fixed), Over Temperature
Rds On (Typ) 95m Ω
Dimensions
Height 1.15mm
Length 7.8mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
