TPS2204APWPRG4
RoHS
RoHS compliant
RoHS compliantPackage 24-TSSOP (0.173, 4.40mm Width) Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Power Distribution Switches, Load Drivers
Description
GULL WING ROHS3Compliant Obsolete Lead Free PCMCIA Switch Power Switch/Driver -40C~85C TA 95m Ohm 1A 3V
PDF
/
Buying Options
Total Price: USD $1.66
Unit Price: USD $1.664711
≥1 USD $1.664711
≥10 USD $1.570477
≥100 USD $1.481583
≥500 USD $1.397718
≥1000 USD $1.318596
Inventory: 1093
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 24-TSSOP (0.173, 4.40mm Width) Exposed Pad
Number of Pins 24
Weight 98.08935mg
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Feature Status Flag
Rds On (Typ) 95m Ω
Fault Protection Current Limiting (Fixed), Over Temperature
Voltage - Load 3.3V 5V 12V
Ratio - Input:Output 3:4
Switch Type PCMCIA Switch
Adjustable Threshold NO
Voltage - Supply (Vcc/Vdd) Not Required
Output Configuration High Side
Current - Output (Max) 1A
Analog IC - Other Type POWER SUPPLY SUPPORT CIRCUIT
Interface Serial
Number of Channels 3
Supply Voltage-Min (Vsup) 3V
Power Supplies 3.3512V
Supply Voltage-Max (Vsup) 3.6V
Qualification Status Not Qualified
Number of Outputs 4
Pin Count 24
Base Part Number TPS2204
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code unknown
Terminal Pitch 0.65mm
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Subcategory Power Management Circuits
Additional Feature ALSO REQUIRES A SUPPLY OF 3 TO 5.5V & 7 TO 13.5V
ECCN Code EAR99
Number of Terminations 24
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Obsolete
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Length 7.8mm
Height Seated (Max) 1.2mm
