TPS2068D
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Power Distribution Switches, Load Drivers
Description
Tube TPS2068 Current Limiting (Fixed) Over Temperature Reverse Current UVLO e4 power distribution switch 4.9mm 5.5V 1.5A 585.82mW
PDF
/
Buying Options
Total Price: USD $0.38
Unit Price: USD $0.38095
≥1 USD $0.38095
≥10 USD $0.3135
≥100 USD $0.30305
≥500 USD $0.29355
≥1000 USD $0.28405
Inventory: 1199
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Surface Mount YES
Number of Pins 8
Weight 72.603129mg
Technical
Operating Temperature 0°C~105°C TJ
Packaging Tube
JESD-609 Code e4
Feature Status Flag
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 8
Termination SMD/SMT
ECCN Code EAR99
Resistance 70mOhm
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Additional Feature UNDERVOLTAGE LOCKOUT
Max Power Dissipation 585.82mW
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3.3V
Base Part Number TPS2068
Pin Count 8
Number of Outputs 1
Output Voltage 6V
Output Type N-Channel
Max Output Current 1.5A
Number of Channels 1
Interface On/Off
Analog IC - Other Type POWER SUPPLY SUPPORT CIRCUIT
Output Configuration High Side
Output Current 1.5A
Voltage - Supply (Vcc/Vdd) Not Required
Adjustable Threshold NO
Input Type Non-Inverting
Max Output Voltage 6V
Switch Type General Purpose
Min Input Voltage 2.7V
Max Input Voltage 5.5V
Supply Current-Max (Isup) 0.07mA
Nominal Input Voltage 5.5V
Ratio - Input:Output 1:1
Voltage - Load 2.7V~5.5V
Fault Protection Current Limiting (Fixed), Over Temperature, Reverse Current, UVLO
Rds On (Typ) 70m Ω
Dimensions
Height 1.75mm
Length 4.9mm
Width 3.91mm
Thickness 1.58mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
