TPS2057AD
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Power Distribution Switches, Load Drivers
Description
Tube TPS2057 Current Limiting (Fixed) Over Temperature UVLO e4 power distribution switch 9.9mm 2.7V 250mA 1.12W
PDF
/
Buying Options
Total Price: USD $6.04
Unit Price: USD $6.043279
≥1 USD $6.043279
≥200 USD $2.339588
≥500 USD $2.256875
≥1000 USD $2.216175
Inventory: 1383
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 1.58mm
Width 3.91mm
Length 9.9mm
Height 1.75mm
Technical
Drain to Source Resistance 100mOhm
Rds On (Typ) 80m Ω
Fault Protection Current Limiting (Fixed), Over Temperature, UVLO
Voltage - Load 2.7V~5.5V
Ratio - Input:Output 1:2, 1:1
Continuous Drain Current (ID) 250mA
Nominal Input Voltage 5.5V
Switch Type General Purpose
Input Type Non-Inverting
Adjustable Threshold NO
Voltage - Supply (Vcc/Vdd) Not Required
Power Dissipation 1.12W
Output Configuration High Side
Analog IC - Other Type POWER SUPPLY SUPPORT CIRCUIT
Interface On/Off
Number of Channels 3
Supply Voltage-Min (Vsup) 2.7V
Output Type N-Channel
Number of Outputs 3
Pin Count 16
Base Part Number TPS2057
Terminal Pitch 1.27mm
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Status Flag
JESD-609 Code e4
Packaging Tube
Operating Temperature 0°C~125°C TJ
Physical
Weight 155.100241mg
Number of Pins 16
Package / Case 16-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
