TPS2052ADR
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Power Distribution Switches, Load Drivers
Description
Tape & Reel (TR) TPS2052 Current Limiting (Fixed) Over Temperature UVLO e4 power distribution switch 4.9mm 3.3V 500mA 725mW
PDF
/
Buying Options
Total Price: USD $4.03
Unit Price: USD $4.028
≥1 USD $4.028
≥10 USD $3.30505
≥100 USD $3.2015
≥500 USD $3.09795
≥1000 USD $2.99535
Inventory: 1094
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Number of Pins 8
Weight 72.603129mg
Technical
Operating Temperature 0°C~125°C TJ
Packaging Tape & Reel (TR)
JESD-609 Code e4
Feature Status Flag
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3.3V
Base Part Number TPS2052
Pin Count 8
Number of Outputs 2
Output Type N-Channel
Supply Voltage-Max (Vsup) 5.5V
Number of Channels 2
Interface On/Off
Analog IC - Other Type POWER SUPPLY SUPPORT CIRCUIT
Output Configuration High Side
Power Dissipation 725mW
Voltage - Supply (Vcc/Vdd) Not Required
Adjustable Threshold NO
Input Type Non-Inverting
Switch Type General Purpose
Continuous Drain Current (ID) 500mA
Ratio - Input:Output 1:2
Voltage - Load 2.7V~5.5V
Fault Protection Current Limiting (Fixed), Over Temperature, UVLO
Rds On (Typ) 80m Ω
Drain to Source Resistance 135mOhm
Dimensions
Height 1.75mm
Length 4.9mm
Width 3.91mm
Thickness 1.58mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
