VNV49N04
RoHS
/
Package PowerSO-10 Exposed Bottom Pad
Category Integrated Circuits (ICs) / PMIC - Power Distribution Switches, Load Drivers
Description
Tube VNV49 Current Limiting (Fixed) Over Temperature Over Voltage e3 power distribution switch 9.4mm 42V 24mus 49A
PDF
/
Inventory: 6414
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case PowerSO-10 Exposed Bottom Pad
Number of Pins 10
Technical
Operating Temperature -40°C~150°C TJ
Packaging Tube
Series OMNIFET?, VIPower?
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 10
ECCN Code EAR99
Resistance 40mOhm
Terminal Finish Matte Tin (Sn) - annealed
Max Power Dissipation 125W
Technology MOS
Terminal Position DUAL
Terminal Form GULL WING
Number of Functions 1
Base Part Number VNV49
Pin Count 10
Number of Outputs 1
Output Type N-Channel
Max Output Current 49A
Operating Supply Voltage 18V
Interface On/Off
Nominal Supply Current 250μA
Output Configuration Low Side
Power Dissipation 125W
Output Current 28A
Voltage - Supply (Vcc/Vdd) Not Required
Max Supply Current 250μA
Input Type Non-Inverting
Switch Type General Purpose
Output Characteristics OPEN-DRAIN
Continuous Drain Current (ID) 49A
Output Polarity TRUE
Ratio - Input:Output 1:1
Input Characteristics SCHMITT TRIGGER
Voltage - Load 33V Max
Fault Protection Current Limiting (Fixed), Over Temperature, Over Voltage
Drain to Source Breakdown Voltage 42V
Turn On Time 3.8 μs
Output Peak Current Limit-Nom 49A
Rds On (Typ) 40m Ω (Max)
Drain to Source Resistance 40mOhm
Turn Off Time 24 μs
Built-in Protections TRANSIENT; OVER CURRENT; OVER VOLTAGE; THERMAL
Dimensions
Height Seated (Max) 3.75mm
Length 9.4mm
Width 7.5mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
