VND830PEP-E
RoHS
RoHS compliant
RoHS compliantPackage 24-PowerBSOP (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / PMIC - Power Distribution Switches, Load Drivers
Description
Tube VND830 Current Limiting (Fixed) Open Load Detect Over Temperature Over Voltage SOURCE power distribution switch 10.3mm 13V 30mus 6A
PDF
/
Buying Options
Total Price: USD $8.06
Unit Price: USD $8.05505
≥1 USD $8.05505
≥10 USD $6.60915
≥100 USD $6.403
≥500 USD $6.1959
≥1000 USD $5.98975
Inventory: 1098
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 7.5mm
Length 10.3mm
Technical
Output Current Flow Direction SOURCE
Built-in Protections TRANSIENT; OVER CURRENT; OVER VOLTAGE; THERMAL; UNDER VOLTAGE
Rds On (Typ) 60m Ω (Max)
Output Peak Current Limit-Nom 9A
Fault Protection Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage
Driver Number of Bits 2
Voltage - Load 5.5V~36V
Ratio - Input:Output 1:1
Turn-Off Delay Time 30 μs
Switch Type General Purpose
Turn On Delay Time 30 μs
Input Type Non-Inverting
Max Supply Current 7mA
Voltage - Supply (Vcc/Vdd) Not Required
Power Dissipation 54W
Output Configuration High Side
Nominal Supply Current 7mA
Interface On/Off
Power Supplies 8/36V
Supply Voltage-Max (Vsup) 36V
Operating Supply Voltage 13V
Max Output Current 6A
Output Type N-Channel
Number of Outputs 2
Pin Count 24
Base Part Number VND830
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 0.8mm
Supply Voltage 13V
Number of Functions 2
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Max Power Dissipation 54W
Subcategory Peripheral Drivers
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 24
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Auto Restart
JESD-609 Code e3
Series VIPower?
Packaging Tube
Operating Temperature -40°C~150°C TJ
Physical
Number of Pins 24
Package / Case 24-PowerBSOP (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 42 Weeks
