VND830
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / PMIC - Power Distribution Switches, Load Drivers
Description
Tube VND830 Current Limiting (Fixed) Open Load Detect Over Temperature Over Voltage e0 power distribution switch 10.3mm 5.5V 6A 8.3W
PDF
/
Buying Options
Total Price: USD $17.76
Unit Price: USD $17.763225
≥1 USD $17.763225
≥10 USD $16.757748
≥100 USD $15.809196
≥500 USD $14.914344
≥1000 USD $14.070127
Inventory: 1580
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 7.5mm
Length 10.3mm
Technical
Built-in Protections TRANSIENT; OVER CURRENT; OVER VOLTAGE; THERMAL; UNDER VOLTAGE
Rds On (Typ) 60m Ω (Max)
Output Peak Current Limit-Nom 9A
Fault Protection Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage
Driver Number of Bits 2
Voltage - Load 5.5V~36V
Ratio - Input:Output 1:1
Switch Type General Purpose
Input Type Non-Inverting
Voltage - Supply (Vcc/Vdd) Not Required
Output Current 9A
Power Dissipation 8.3W
Output Configuration High Side
Nominal Supply Current 12μA
Interface On/Off
Supply Voltage-Min (Vsup) 5.5V
Power Supplies 8/36V
Supply Voltage-Max (Vsup) 36V
Max Output Current 6A
Output Type N-Channel
Number of Outputs 2
Pin Count 16
Base Part Number VND830
Supply Voltage 13V
Number of Functions 1
Terminal Form GULL WING
Terminal Position DUAL
Technology MOS
Max Power Dissipation 8.3W
Subcategory Peripheral Drivers
Terminal Finish TIN LEAD
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
Feature Auto Restart, Status Flag
JESD-609 Code e0
Series VIPower?
Packaging Tube
Operating Temperature -40°C~150°C TJ
Physical
Number of Pins 16
Package / Case 16-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
