VND810PEPTR-E
RoHS
RoHS compliant
RoHS compliantPackage 12-PowerLSOP (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Power Distribution Switches, Load Drivers
Description
Tape & Reel (TR) VND810 Current Limiting (Fixed) Open Load Detect Over Temperature Over Voltage SOURCE power distribution switch 4.9mm 13V 30mus 3.5A
PDF
/
Buying Options
Total Price: USD $37.42
Unit Price: USD $37.423444
≥1 USD $37.423444
≥10 USD $35.305136
≥100 USD $33.306731
≥500 USD $31.421448
≥1000 USD $29.642873
Inventory: 1371
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 3.9mm
Length 4.9mm
Technical
Output Current Flow Direction SOURCE
Built-in Protections TRANSIENT; OVER CURRENT; OVER VOLTAGE; THERMAL; UNDER VOLTAGE
Rds On (Typ) 160m Ω (Max)
Output Peak Current Limit-Nom 5A
Fault Protection Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage
Driver Number of Bits 2
Voltage - Load 5.5V~36V
Ratio - Input:Output 1:1
Turn-Off Delay Time 30 μs
Switch Type General Purpose
Turn On Delay Time 30 μs
Input Type Non-Inverting
Max Supply Current 25μA
Voltage - Supply (Vcc/Vdd) Not Required
Power Dissipation 54W
Output Configuration High Side
Nominal Supply Current 25μA
Interface On/Off
Power Supplies 8/36V
Supply Voltage-Max (Vsup) 36V
Operating Supply Voltage 13V
Max Output Current 3.5A
Output Type N-Channel
Number of Outputs 2
Pin Count 12
Base Part Number VND810
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 0.8mm
Supply Voltage 13V
Number of Functions 2
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Max Power Dissipation 54W
Subcategory Peripheral Drivers
Terminal Finish Matte Tin (Sn)
Resistance 160mOhm
ECCN Code EAR99
Number of Terminations 12
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Feature Auto Restart, Status Flag
JESD-609 Code e3
Series VIPower?
Packaging Tape & Reel (TR)
Operating Temperature -40°C~150°C TJ
Physical
Number of Pins 12
Package / Case 12-PowerLSOP (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status NRND (Last Updated: 7 months ago)
Factory Lead Time 18 Weeks
Alternative Model
