VND600PEPTR-E
RoHS
RoHS compliant
RoHS compliantPackage 24-PowerBSOP (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / PMIC - Power Distribution Switches, Load Drivers
Description
Tape & Reel (TR) VND600 Current Limiting (Fixed) Over Temperature Over Voltage On/Off power distribution switch 10.3mm 36V 40A 96W
PDF
/
Buying Options
Total Price: USD $1.78
Unit Price: USD $1.7784
≥1 USD $1.7784
≥10 USD $1.4592
≥100 USD $1.4136
≥500 USD $1.368
≥1000 USD $1.3224
Inventory: 71687
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 42 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 24-PowerBSOP (0.295, 7.50mm Width)
Number of Pins 24
Technical
Operating Temperature -40°C~150°C TJ
Packaging Tape & Reel (TR)
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 24
ECCN Code EAR99
Resistance 30mOhm
Subcategory Peripheral Drivers
Max Power Dissipation 96W
Terminal Position DUAL
Terminal Form GULL WING
Number of Functions 1
Supply Voltage 13V
Terminal Pitch 0.8mm
Base Part Number VND600
Pin Count 24
Number of Outputs 2
Output Type N-Channel
Max Output Current 40A
Operating Supply Voltage 36V
Interface On/Off
Nominal Supply Current 6mA
Output Configuration High Side
Power Dissipation 96W
Output Current 25A
Voltage - Supply (Vcc/Vdd) Not Required
Max Supply Current 6mA
Input Type Non-Inverting
Switch Type General Purpose
Min Input Voltage 5.5V
Max Input Voltage 36V
Ratio - Input:Output 1:1
Voltage - Load 5.5V~36V
Driver Number of Bits 2
Fault Protection Current Limiting (Fixed), Over Temperature, Over Voltage
Rds On (Typ) 30m Ω (Max)
Built-in Protections TRANSIENT; OVER CURRENT; OVER VOLTAGE; THERMAL; UNDER VOLTAGE
Dimensions
Length 10.3mm
Width 7.5mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
