VN750PT13TR
RoHS
RoHS compliant
RoHS compliantPackage TO-252-5, DPak (4 Leads + Tab), TO-252AD
Category Integrated Circuits (ICs) / PMIC - Power Distribution Switches, Load Drivers
Description
Tape & Reel (TR) VN750 Current Limiting (Fixed) Open Load Detect Over Temperature Over Voltage e0 power distribution switch 2.63mm 13V 40mus 6A
PDF
/
Buying Options
Total Price: USD $11.06
Unit Price: USD $11.0599
≥1 USD $11.0599
≥10 USD $9.07535
≥100 USD $8.7913
≥500 USD $8.5082
≥1000 USD $8.22415
Inventory: 1212
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height Seated (Max) 2.63mm
Technical
Built-in Protections TRANSIENT; OVER CURRENT; OVER VOLTAGE; THERMAL; UNDER VOLTAGE
Rds On (Typ) 60m Ω (Max)
Output Peak Current Limit-Nom 9A
Fault Protection Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage
Driver Number of Bits 1
Voltage - Load 5.5V~36V
Ratio - Input:Output 1:1
Turn-Off Delay Time 30 μs
Output Current per Channel 6A
Switch Type General Purpose
Turn On Delay Time 40 μs
Input Type Non-Inverting
Max Supply Current 3.5mA
Voltage - Supply (Vcc/Vdd) Not Required
Output Current 6A
Power Dissipation 60W
Output Configuration High Side
Nominal Supply Current 2mA
Interface On/Off
Power Supplies 8/36V
Supply Voltage-Max (Vsup) 36V
Operating Supply Voltage 13V
Max Output Current 6A
Output Type N-Channel
Number of Outputs 1
JESD-30 Code R-PSSO-G4
Pin Count 4
Base Part Number VN750
Supply Voltage 13V
Number of Functions 1
Terminal Form GULL WING
Terminal Position SINGLE
Max Power Dissipation 60W
Subcategory Peripheral Drivers
Terminal Finish Tin/Lead (Sn/Pb)
Resistance 60mOhm
ECCN Code EAR99
Number of Terminations 4
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code no
Feature Auto Restart, Status Flag
JESD-609 Code e0
Series VIPower?
Packaging Tape & Reel (TR)
Operating Temperature -40°C~150°C TJ
Physical
Number of Pins 5
Package / Case TO-252-5, DPak (4 Leads + Tab), TO-252AD
Mounting Type Surface Mount
Mount Surface Mount
