VN750PT-E
RoHS
RoHS compliant
RoHS compliantPackage TO-252-5, DPak (4 Leads + Tab), TO-252AD
Category Integrated Circuits (ICs) / PMIC - Power Distribution Switches, Load Drivers
Description
Tube VN750 Current Limiting (Fixed) Open Load Detect Over Temperature Over Voltage e3 power distribution switch 6.6mm 13V 40mus 6A
PDF
/
Buying Options
Total Price: USD $4.03
Unit Price: USD $4.028
≥1 USD $4.028
≥10 USD $3.30505
≥100 USD $3.2015
≥500 USD $3.09795
≥1000 USD $2.99535
Inventory: 23990
Minimum: 1
-
+
Technical Details
Technical
Max Supply Current 3.5mA
Input Type Non-Inverting
Turn On Delay Time 40 μs
Switch Type General Purpose
Output Current per Channel 6A
Turn-Off Delay Time 30 μs
Ratio - Input:Output 1:1
Voltage - Load 5.5V~36V
Fault Protection Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage
Number of Drivers 1
Output Peak Current Limit-Nom 9A
Rds On (Typ) 60m Ω (Max)
Built-in Protections TRANSIENT; OVER CURRENT; OVER VOLTAGE; THERMAL; UNDER VOLTAGE
On-State Resistance 60mOhm
Voltage - Supply (Vcc/Vdd) Not Required
Output Current 6A
Power Dissipation 60W
Output Configuration High Side
Nominal Supply Current 2mA
Interface On/Off
Power Supplies 8/36V
Supply Voltage-Max (Vsup) 36V
Operating Supply Voltage 13V
Max Output Current 6A
Output Type N-Channel
Pin Count 5
Base Part Number VN750
Supply Voltage 13V
Number of Functions 1
Terminal Form GULL WING
Terminal Position SINGLE
Max Power Dissipation 60W
Subcategory Peripheral Drivers
Terminal Finish Matte Tin (Sn) - annealed
Resistance 60mOhm
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Feature Auto Restart, Status Flag
JESD-609 Code e3
Series VIPower?
Packaging Tube
Operating Temperature -40°C~150°C TJ
Dimensions
Height 2.63mm
Length 6.6mm
Width 6.2mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Physical
Weight 4.535924g
Number of Pins 5
Package / Case TO-252-5, DPak (4 Leads + Tab), TO-252AD
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 20 Weeks
