VN7140AS-E
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Power Distribution Switches, Load Drivers
Description
Tube VN7140 Current Limiting (Fixed) Open Load Detect Over Temperature Over Voltage UVLO On/Off power distribution switch 4.9mm 4V 120mus 8A
PDF
/
Inventory: 5510
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 3.9mm
Length 4.9mm
Technical
Built-in Protections TRANSIENT; OVER CURRENT; OVER VOLTAGE; THERMAL; UNDER VOLTAGE
Rds On (Typ) 140m Ω
Fault Protection Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage, UVLO
Voltage - Load 4V~28V
Ratio - Input:Output 1:1
Turn-Off Delay Time 100 μs
Switch Type General Purpose
Turn On Delay Time 120 μs
Input Type Non-Inverting
Max Supply Current 5mA
Voltage - Supply (Vcc/Vdd) Not Required
Output Current 8A
Output Configuration High Side
Nominal Supply Current 3mA
Interface On/Off
Supply Voltage-Min (Vsup) 4V
Max Output Current 8A
Output Type N-Channel
Number of Outputs 1
Base Part Number VN7140
Supply Voltage 13V
Number of Functions 1
Terminal Form GULL WING
Terminal Position DUAL
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Discontinued
Feature Auto Restart, Status Flag
Series VIPower?
Packaging Tube
Operating Temperature -40°C~150°C TJ
Physical
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
