VN5E050J-E
RoHS
RoHS compliant
RoHS compliantPackage PowerSSO-12
Category Integrated Circuits (ICs) / PMIC - Power Distribution Switches, Load Drivers
Description
Tube VN5E050 Current Limiting (Fixed) Open Load Detect Over Temperature Over Voltage SINK power distribution switch 4.9mm 13V 20mus 27A
PDF
/
Buying Options
Total Price: USD $6.17
Unit Price: USD $6.175
≥1 USD $6.175
≥10 USD $5.0673
≥100 USD $4.90865
≥500 USD $4.75
≥1000 USD $4.5923
Inventory: 1156
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case PowerSSO-12
Number of Pins 12
Technical
Operating Temperature -40°C~150°C TJ
Packaging Tube
Series VIPower?
Feature Auto Restart
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 12
ECCN Code EAR99
Resistance 50mOhm
Subcategory Peripheral Drivers
Terminal Position DUAL
Terminal Form GULL WING
Number of Functions 1
Supply Voltage 13V
Terminal Pitch 0.8mm
Base Part Number VN5E050
Pin Count 12
Number of Outputs 1
Output Type N-Channel
Max Output Current 27A
Operating Supply Voltage 13V
Supply Voltage-Max (Vsup) 28V
Power Supplies 8/28V
Interface On/Off
Nominal Supply Current 6mA
Output Configuration High Side
Voltage - Supply (Vcc/Vdd) Not Required
Max Supply Current 6mA
Input Type Non-Inverting
Turn On Delay Time 20 μs
Switch Type General Purpose
Output Current per Channel 19A
Turn-Off Delay Time 40 μs
Ratio - Input:Output 1:1
Voltage - Load 4.5V~28V
Driver Number of Bits 1
Fault Protection Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage
Rds On (Typ) 50m Ω (Max)
Built-in Protections TRANSIENT; OVER CURRENT; THERMAL; UNDER VOLTAGE
Output Current Flow Direction SINK
Dimensions
Length 4.9mm
Width 3.9mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
