VN540-12-E
RoHS
RoHS compliant
RoHS compliantPackage Pentawatt-5 (Straight Leads, Staggered Depth)
Category Integrated Circuits (ICs) / PMIC - Power Distribution Switches, Load Drivers
Description
Tube VN540 Current Limiting (Fixed) Over Temperature e3 power distribution switch 10.4mm 24V 4A 50m Ohm (Max)
PDF
/
Inventory: 1655
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 4.8mm
Length 10.4mm
Height 9.2mm
Technical
Built-in Protections OVER CURRENT; THERMAL; UNDER VOLTAGE
Rds On (Typ) 50m Ω (Max)
Fault Protection Current Limiting (Fixed), Over Temperature
Driver Number of Bits 1
Voltage - Load 10V~36V
Ratio - Input:Output 1:1
Output Current per Channel 2.8A
Switch Type General Purpose
Input Type Non-Inverting
Max Supply Current 1mA
Voltage - Supply (Vcc/Vdd) Not Required
Output Current 2.8A
Output Configuration High Side
Nominal Supply Current 1mA
Interface On/Off
Supply Voltage-Max (Vsup) 36V
Max Output Current 4A
Qualification Status Not Qualified
Number of Outputs 1
Base Part Number VN540
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 24V
Number of Functions 1
Peak Reflow Temperature (Cel) 225
Terminal Position SINGLE
Subcategory Peripheral Drivers
Terminal Finish MATTE TIN
Resistance 50mOhm
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Status Flag
JESD-609 Code e3
Series VIPower?
Packaging Tube
Operating Temperature -25°C~85°C TJ
Physical
Number of Pins 5
Package / Case Pentawatt-5 (Straight Leads, Staggered Depth)
Mounting Type Through Hole
Mount Through Hole
Alternative Model
