VN06SP-E
RoHS
RoHS compliant
RoHS compliantPackage PowerSO-10 Exposed Bottom Pad
Category Integrated Circuits (ICs) / PMIC - Power Distribution Switches, Load Drivers
Description
Tube VN06 Open Load Detect Over Temperature e3 power distribution switch 7.6mm 26V 1.9A 27W
PDF
/
Buying Options
Total Price: USD $5.37
Unit Price: USD $5.37035
≥1 USD $5.37035
≥10 USD $4.4061
≥100 USD $4.26835
≥500 USD $4.1306
≥1000 USD $3.99285
Inventory: 37
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 9.5mm
Length 7.6mm
Height 3.65mm
Technical
Built-in Protections TRANSIENT; THERMAL; UNDER VOLTAGE
Rds On (Typ) 180m Ω (Max)
Output Peak Current Limit-Nom 0.18A
Fault Protection Open Load Detect, Over Temperature
Driver Number of Bits 1
Voltage - Load 5.5V~26V
Ratio - Input:Output 1:1
Output Current per Channel 1.9A
Max Input Voltage 26V
Min Input Voltage 5.5V
Switch Type General Purpose
Input Type Non-Inverting
Max Supply Current 15mA
Voltage - Supply (Vcc/Vdd) Not Required
Output Current 9A
Power Dissipation 27W
Output Configuration High Side
Nominal Supply Current 15mA
Interface On/Off
Operating Supply Voltage 26V
Max Output Current 9A
Output Type N-Channel
Number of Outputs 1
Pin Count 10
Base Part Number VN06
Current Rating 1.9A
Supply Voltage 13V
Number of Functions 1
Terminal Form GULL WING
Terminal Position DUAL
Max Power Dissipation 27W
Subcategory Peripheral Drivers
Terminal Finish Matte Tin (Sn) - annealed
Resistance 180mOhm
ECCN Code EAR99
Number of Terminations 10
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Feature Status Flag
JESD-609 Code e3
Packaging Tube
Operating Temperature -40°C~150°C TJ
Physical
Number of Pins 10
Package / Case PowerSO-10 Exposed Bottom Pad
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 42 Weeks
Alternative Model
