ST2051BDR
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Power Distribution Switches, Load Drivers
Description
Tape & Reel (TR) ST2051 Current Limiting (Fixed) Over Temperature UVLO On/Off power distribution switch 4.9mm 2.7V 500mA 80m Ohm
PDF
/
Buying Options
Total Price: USD $10.74
Unit Price: USD $10.7388
≥1 USD $10.7388
≥10 USD $8.81125
≥100 USD $8.53575
≥500 USD $8.26025
≥1000 USD $7.9857
Inventory: 1216
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Number of Pins 8
Technical
Operating Temperature -40°C~125°C TJ
Packaging Tape & Reel (TR)
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 8
ECCN Code EAR99
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Supply Voltage 5V
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number ST2051
Pin Count 8
Number of Outputs 1
Qualification Status Not Qualified
Output Type N-Channel
Supply Voltage-Min (Vsup) 2.7V
Number of Channels 1
Interface On/Off
Analog IC - Other Type POWER SUPPLY SUPPORT CIRCUIT
Current - Output (Max) 500mA
Output Configuration High Side
Output Current 0A
Voltage - Supply (Vcc/Vdd) Not Required
Adjustable Threshold NO
Input Type Non-Inverting
Switch Type General Purpose
Nominal Input Voltage 5V
Ratio - Input:Output 1:1
Voltage - Load 2.7V~5.5V
Fault Protection Current Limiting (Fixed), Over Temperature, UVLO
Rds On (Typ) 80m Ω
Dimensions
Length 4.9mm
Width 3.9mm
Compliance
RoHS Status ROHS3 Compliant
Alternative Model
