L9352B-LF
RoHS
RoHS compliant
RoHS compliantPackage 36-BSSOP (0.433, 11.00mm Width) Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Power Distribution Switches, Load Drivers
Description
Tube L9352 Open Load Detect Over Temperature SOURCE power distribution switch 15.9mm 5V 30μs 2.5A 5A
PDF
/
Buying Options
Total Price: USD $27.65
Unit Price: USD $27.64975
≥1 USD $27.64975
≥10 USD $22.68695
≥100 USD $21.97825
≥500 USD $21.2686
≥1000 USD $20.5599
Inventory: 1636
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Lifecycle Status ACTIVE (Last Updated: 6 months ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 36-BSSOP (0.433, 11.00mm Width) Exposed Pad
Number of Pins 36
Technical
Operating Temperature -40°C~150°C TJ
Packaging Tube
JESD-609 Code e3
Feature Status Flag
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 36
ECCN Code EAR99
Resistance 200mOhm
Terminal Finish Matte Tin (Sn) - annealed
Subcategory Peripheral Drivers
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 245
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 0.65mm
Base Part Number L9352
Pin Count 36
Number of Outputs 4
Output Type N-Channel
Max Output Current 7.5A
Supply Voltage-Max (Vsup) 18V
Interface Parallel
Current - Output (Max) 2.5A 5A
Nominal Supply Current 5mA
Output Configuration Low Side
Voltage - Supply (Vcc/Vdd) 4.5V~5.5V
Max Supply Current 5mA
Input Type Non-Inverting
Switch Type General Purpose
Output Current per Channel 5A
Ratio - Input:Output 1:1
Voltage - Load 4.8V~18V
Driver Number of Bits 4
Fault Protection Open Load Detect, Over Temperature
Turn On Time 20 μs
Rds On (Typ) 200m Ω
Turn Off Time 30 μs
Built-in Protections TRANSIENT
Output Current Flow Direction SOURCE
Dimensions
Height Seated (Max) 3.6mm
Length 15.9mm
Width 11mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
