MIC2039AYMT-T5
RoHS
RoHS compliant
RoHS compliantPackage 6-UFDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Power Distribution Switches, Load Drivers
Description
Cut Tape (CT) MIC2039 Current Limiting (Adjustable) Over Temperature UVLO On/Off power distribution switch 5.5V 700mus 2.5A 75mOhm
PDF
/
Inventory: 3357
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Technical
Rds On (Typ) 75mOhm
Fault Protection Current Limiting (Adjustable), Over Temperature, UVLO
Voltage - Load 2.5V~5.5V
Ratio - Input:Output 1:1
Turn-Off Delay Time 5 μs
Switch Type General Purpose
Turn On Delay Time 700 μs
Input Type Non-Inverting
Voltage - Supply (Vcc/Vdd) Not Required
Output Configuration High Side
Nominal Supply Current 100μA
Current - Output (Max) 2.5A
Min Supply Voltage 2.5V
Max Supply Voltage 5.5V
Interface On/Off
Max Output Current 2.5A
Output Type P-Channel
Number of Outputs 1
Base Part Number MIC2039
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Resistance 177mOhm
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Discontinued
Feature Slew Rate Controlled, Status Flag
Published 2016
Packaging Cut Tape (CT)
Operating Temperature -40°C~125°C TJ
Physical
Supplier Device Package 6-TDFN (2x2)
Package / Case 6-UFDFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 18 Weeks
