MIC2026-2YM
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Power Distribution Switches, Load Drivers
Description
Tube MIC2026 Current Limiting (Fixed) Over Temperature UVLO On/Off power distribution switch 5mm 5.5V 5ms 500mA
PDF
/
Buying Options
Total Price: USD $1.19
Unit Price: USD $1.188
≥1 USD $1.188
≥10 USD $0.9944
≥100 USD $0.8976
Inventory: 1492
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 3.99mm
Length 5mm
Height 1.73mm
Technical
Ambient Temperature Range High 85°C
Drain to Source Resistance 140mOhm
Rds On (Typ) 90mOhm
Load Current 500mA
Fault Protection Current Limiting (Fixed), Over Temperature, UVLO
Voltage - Load 2.7V~5.5V
Ratio - Input:Output 1:2
Turn-Off Delay Time 100 μs
Nominal Input Voltage 5.5V
Max Input Voltage 5.5V
Min Input Voltage 2.7V
Switch Type General Purpose
Turn On Delay Time 5 ms
Input Type Non-Inverting
Voltage - Supply (Vcc/Vdd) Not Required
Output Current 500mA
Output Configuration High Side
Nominal Supply Current 20μA
Current - Output (Max) 500mA
Min Supply Voltage 2.7V
Max Supply Voltage 5.5V
Interface On/Off
Number of Channels 2
Max Output Current 500mA
Output Type N-Channel
Output Voltage 6V
Number of Outputs 2
Base Part Number MIC2026
Current Rating 1.25A
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Resistance 90mOhm
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Slew Rate Controlled, Status Flag
Published 2007
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Supplier Device Package 8-SOIC
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
