MIC2016-0.8YML-TR

Microchip Technology
RoHS
RoHS RoHS compliant
Package 6-VDFN Exposed Pad, 6-MLF?
Category Integrated Circuits (ICs) / PMIC - Power Distribution Switches, Load Drivers
Description ROHS3Compliant Non-Inverting Obsolete Lead Free General Purpose Power Switch/Driver -40C~85C TA 70mOhm 800mA 5.5V
PDF
/
Inventory: 2564
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Technical

Rds On (Typ) 70mOhm
Fault Protection Current Limiting (Fixed), Over Temperature, UVLO
Voltage - Load 2.5V~5.5V
Ratio - Input:Output 1:1
Switch Type General Purpose
Input Type Non-Inverting
Voltage - Supply (Vcc/Vdd) Not Required
Output Configuration High Side
Current - Output (Max) 800mA
Max Supply Voltage 5.5V
Interface On/Off
Max Output Current 800mA
Output Type P-Channel
Number of Outputs 1
Base Part Number MIC2016
Current Rating 800mA
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Resistance 100MOhm
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Slew Rate Controlled
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA

Physical

Supplier Device Package 6-MLF? (2x2)
Number of Pins 6
Package / Case 6-VDFN Exposed Pad, 6-MLF?
Mounting Type Surface Mount
Mount Surface Mount
