MIC2015-0.8YM6-TR

Microchip Technology
RoHS
RoHS RoHS compliant
Package SOT-23-6
Category Integrated Circuits (ICs) / PMIC - Power Distribution Switches, Load Drivers
Description Tape & Reel (TR) MIC2015 Current Limiting (Fixed) Over Temperature On/Off power distribution switch 5.5V 800mA 70mOhm -40C~85C TA
PDF
/
Buying Options
Total Price: USD $1.22
Unit Price: USD $1.2232
≥1 USD $1.2232
≥10 USD $1.0208
≥100 USD $0.9328
Inventory: 546
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Technical

Rds On (Typ) 70mOhm
Fault Protection Current Limiting (Fixed), Over Temperature
Voltage - Load 2.5V~5.5V
Ratio - Input:Output 1:1
Switch Type General Purpose
Input Type Non-Inverting
Voltage - Supply (Vcc/Vdd) Not Required
Output Configuration High Side
Current - Output (Max) 800mA
Max Supply Voltage 5.5V
Interface On/Off
Number of Channels 1
Max Output Current 800mA
Output Type P-Channel
Output Voltage 6V
Number of Outputs 1
Base Part Number MIC2015
Current Rating 800mA
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Resistance 100MOhm
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Slew Rate Controlled
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA

Physical

Supplier Device Package SOT-23-6
Number of Pins 6
Package / Case SOT-23-6
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 13 Weeks
