AUIPS6041
RoHS
/
Package TO-220-5
Category Integrated Circuits (ICs) / PMIC - Power Distribution Switches, Load Drivers
Description
Tube AUIPS6041 Current Limiting (Fixed) Open Load Detect Over Temperature On/Off power distribution switch 10.67mm 5.5V 10mus 7A
PDF
/
Buying Options
Total Price: USD $30.41
Unit Price: USD $30.41425
≥1 USD $30.41425
≥10 USD $24.95555
≥100 USD $24.1756
≥500 USD $23.39565
≥1000 USD $22.6157
Inventory: 1119
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 4.83mm
Length 10.67mm
Height 16.51mm
Technical
Built-in Protections TRANSIENT; OVER CURRENT
Turn Off Time 20 μs
Rds On (Typ) 110m Ω
Output Peak Current Limit-Nom 7A
Fault Protection Current Limiting (Fixed), Open Load Detect, Over Temperature
Driver Number of Bits 1
Voltage - Load 6V~28V
Ratio - Input:Output 1:1
Nominal Input Voltage 5.5V
Fall Time (Typ) 10 μs
Rise Time 10 μs
Switch Type General Purpose
Input Type Non-Inverting
Voltage - Supply (Vcc/Vdd) Not Required
Output Current 4A
Output Configuration High Side
Current 7A
Nominal Supply Current 2.2mA
Interface On/Off
Voltage 36.3V
Power Supplies 6/28V
Output Type N-Channel
Number of Outputs 1
Base Part Number AUIPS6041
Supply Voltage 14V
Number of Functions 1
Terminal Position SINGLE
Subcategory Peripheral Drivers
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Auto Restart
Series Automotive, AEC-Q100
Published 2012
Packaging Tube
Operating Temperature -40°C~150°C TJ
Physical
Number of Pins 5
Package / Case TO-220-5
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 18 Weeks
