TLE7230R
RoHS
/
Package /
Category Integrated Circuits (ICs) / PMIC - Power Distribution Switches, Load Drivers
Description
SINK e3 MOS TRANSIENT; OVER CURRENT; OVER VOLTAGE; THERMAL power distribution switch 15.9mm 4.5V 60mus 1A
PDF
/
Buying Options
Total Price: USD $4.19
Unit Price: USD $4.192621
≥1 USD $4.192621
≥10 USD $3.29523
≥100 USD $2.748423
≥500 USD $7.4442
≥1000 USD $7.19625
Inventory: 5
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 11mm
Length 15.9mm
Height Seated (Max) 3.5mm
Technical
Output Current Flow Direction SINK
Built-in Protections TRANSIENT; OVER CURRENT; OVER VOLTAGE; THERMAL
Turn Off Time 60 μs
Output Peak Current Limit-Nom 1A
Turn On Time 60 μs
Screening Level AEC-Q100
Driver Number of Bits 8
Interface IC Type BUFFER OR INVERTER BASED PERIPHERAL DRIVER
Supply Voltage-Min (Vsup) 4.5V
Power Supplies 5V
Supply Voltage-Max (Vsup) 5.5V
Qualification Status Not Qualified
JESD-30 Code R-PDSO-G36
Pin Count 36
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code compliant
Terminal Pitch 0.65mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Technology MOS
Subcategory Peripheral Drivers
HTS Code 8542.39.00.01
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 3
Pbfree Code icon-pbfree no
JESD-609 Code e3
Physical
Number of Terminals 36
Surface Mount YES
