UCC28510N
RoHS
RoHS compliant
RoHS compliantPackage 20-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / PMIC - PFC (Power Factor Correction)
Description
Through Hole Obsolete ROHS3Compliant BICMOS PFC IC Average Current -40C~105C 5.08mm 100muA 500kHz
PDF
/
Buying Options
Total Price: USD $13.42
Unit Price: USD $13.42445
≥1 USD $13.42445
≥10 USD $11.01525
≥100 USD $10.6704
≥500 USD $10.3265
≥1000 USD $9.9826
Inventory: 8096
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height Seated (Max) 5.08mm
Technical
Current - Startup 100μA
Mode Average Current
Switcher Configuration BOOST
Control Technique PULSE WIDTH MODULATION
Input Voltage (Max) 15V
Frequency - Switching 200kHz
Output Current-Max 3.5A
Input Voltage (Min) 10.8V
Quiescent Current 4mA
Analog IC - Other Type POWER FACTOR CONTROLLER WITH POST REGULATOR
Input Voltage-Nom 12V
Number of Outputs 2
Pin Count 20
Base Part Number UCC28510
Frequency 500kHz
Number of Functions 1
Terminal Position DUAL
Voltage - Supply 9.7V~18V
Technology BICMOS
Subcategory Switching Regulator or Controllers
Additional Feature PEAK CURRENT MODE ALSO AVAILABLE
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Packaging Tube
Operating Temperature -40°C~105°C
Physical
Weight 1.1991g
Number of Pins 20
Surface Mount NO
Package / Case 20-DIP (0.300, 7.62mm)
Mounting Type Through Hole
