UCC2818DW
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / PMIC - PFC (Power Factor Correction)
Description
Tube UCC2818 ACTIVE (Last Updated: 23hours ago) e4 power factor correction device 12V~17V 250kHz 150muA 2.65mm
PDF
/
Buying Options
Total Price: USD $1.11
Unit Price: USD $1.10675
≥1 USD $1.10675
≥10 USD $0.9082
≥100 USD $0.8797
≥500 USD $0.8512
≥1000 USD $0.8227
Inventory: 6474
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 23 hours ago)
Physical
Mounting Type Surface Mount
Package / Case 16-SOIC (0.295, 7.50mm Width)
Surface Mount YES
Number of Pins 16
Weight 473.692182mg
Technical
Operating Temperature -40°C~85°C
Packaging Tube
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 2 (1 Year)
Number of Terminations 16
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Switching Regulator or Controllers
Technology BICMOS
Voltage - Supply 12V~17V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 12V
Frequency 250kHz
Base Part Number UCC2818
Pin Count 16
Number of Outputs 1
Input Voltage-Nom 12V
Analog IC - Other Type POWER FACTOR CONTROLLER
Max Supply Current 20mA
Frequency - Switching 6kHz~220kHz
Control Technique PULSE WIDTH MODULATION
Switcher Configuration BOOST
Mode Average Current
Current - Startup 150μA
Dimensions
Height 2.65mm
Length 10.3mm
Width 7.5mm
Thickness 2.35mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Alternative Model
