UC2852NG4
RoHS
/
Package PDIP
Category Integrated Circuits (ICs) / PMIC - PFC (Power Factor Correction)
Description
INDUSTRIAL Through Hole RoHS Compliant BIPOLAR PFC IC (Mode) 85C 5.33mm 1A 200kHz
PDF
/
Buying Options
Total Price: USD $2.67
Unit Price: USD $2.6664
≥1 USD $2.6664
Inventory: 138
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Package / Case PDIP
Number of Pins 8
Weight 528.605208mg
Technical
JESD-609 Code e4
Pbfree Code yes
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Subcategory Switching Regulator or Controllers
Technology BIPOLAR
Terminal Position DUAL
Number of Functions 1
Terminal Pitch 2.54mm
Frequency 200kHz
Pin Count 8
Input Voltage-Nom 24V
Temperature Grade INDUSTRIAL
Max Supply Voltage 30V
Analog IC - Other Type POWER FACTOR CONTROLLER
Input Voltage (Min) 12.5V
Control Mode CURRENT-MODE
Output Current-Max 1A
Frequency - Switching 200kHz
Control Technique PULSE WIDTH MODULATION
Switcher Configuration SINGLE
Dimensions
Height Seated (Max) 5.33mm
Width 7.62mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
