UCC28503N
RoHS
RoHS compliant
RoHS compliantPackage 20-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / PMIC - PFC (Power Factor Correction)
Description
Through Hole Obsolete ROHS3Compliant BICMOS PFC IC Average Current -40C~85C 5.08mm 150muA 80kHz~120kHz
PDF
/
Inventory: 4123
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Through Hole
Package / Case 20-DIP (0.300, 7.62mm)
Surface Mount NO
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 20
Terminal Finish NOT SPECIFIED
Additional Feature CAN ALSO BE PROGRAMMED FOR CURRENT MODE AND VOLTAGE MODE
Technology BICMOS
Voltage - Supply 9.7V~18V
Terminal Position DUAL
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Terminal Pitch 2.54mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 20
JESD-30 Code R-PDIP-T20
Input Voltage-Nom 12V
Analog IC - Other Type POWER FACTOR CONTROLLER WITH POST REGULATOR
Input Voltage (Min) 10.3V
Output Current-Max 1.2A
Frequency - Switching 80kHz~120kHz
Input Voltage (Max) 15V
Control Technique PULSE WIDTH MODULATION
Switcher Configuration BOOST
Mode Average Current
Current - Startup 150μA
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 7.62mm
Length 25.4mm
Height Seated (Max) 5.08mm
