NCP1650DR2
RoHS
/
Package 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - PFC (Power Factor Correction)
Description
GULL WING Surface Mount Obsolete Non-RoHS Compliant PFC IC Continuous Conduction (CCM), Discontinuous Conduction (DCM) -40C~125C 1.75mm 100kHz 10V~20V
PDF
/
Inventory: /
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 16-SOIC (0.154, 3.90mm Width)
Surface Mount YES
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
JESD-609 Code e0
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
Terminal Finish TIN LEAD
Voltage - Supply 10V~20V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 240
Number of Functions 1
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) 30
Pin Count 16
JESD-30 Code R-PDSO-G16
Qualification Status COMMERCIAL
Input Voltage-Nom 14V
Analog IC - Other Type POWER FACTOR CONTROLLER
Input Voltage (Min) 10.5V
Frequency - Switching 100kHz
Control Technique PULSE WIDTH MODULATION
Switcher Configuration SINGLE
Mode Continuous Conduction (CCM), Discontinuous Conduction (DCM)
Dimensions
Height Seated (Max) 1.75mm
Length 9.9mm
Width 3.9mm
Compliance
RoHS Status Non-RoHS Compliant
