NCP1601BPG
RoHS
RoHS compliant
RoHS compliantPackage 8-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / PMIC - PFC (Power Factor Correction)
Description
Through Hole Obsolete ROHS3Compliant COMMERCIAL PFC IC Critical Conduction (CRM), Discontinuous (Transition) -40C~125C 5.33mm 17muA 58kHz
PDF
/
Buying Options
Total Price: USD $9.34
Unit Price: USD $9.3423
≥1 USD $9.3423
≥10 USD $7.66555
≥100 USD $7.42615
≥500 USD $7.1858
≥1000 USD $6.9464
Inventory: 10008
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 7.62mm
Length 9.27mm
Height Seated (Max) 5.33mm
Technical
Current - Startup 17μA
Mode Critical Conduction (CRM), Discontinuous (Transition)
Switcher Configuration BOOST
Control Technique PULSE WIDTH MODULATION
Input Voltage (Max) 18V
Frequency - Switching 58kHz
Output Current-Max 0.75A
Input Voltage (Min) 9.75V
Analog IC - Other Type POWER FACTOR CONTROLLER
Input Voltage-Nom 15V
Qualification Status COMMERCIAL
JESD-30 Code R-PDIP-T8
Pin Count 8
Time@Peak Reflow Temperature-Max (s) 40
Reach Compliance Code unknown
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Voltage - Supply 9.6V~18V
Terminal Finish MATTE TIN
Number of Terminations 8
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e3
Packaging Tube
Operating Temperature -40°C~125°C
Physical
Surface Mount NO
Package / Case 8-DIP (0.300, 7.62mm)
Mounting Type Through Hole
