NCP1601AP
RoHS
/
Package 8-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / PMIC - PFC (Power Factor Correction)
Description
Through Hole Obsolete Non-RoHS Compliant COMMERCIAL PFC IC Critical Conduction (CRM), Discontinuous (Transition) -40C~125C 4.45mm 17muA 58kHz
PDF
/
Inventory: 9877
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Through Hole
Package / Case 8-DIP (0.300, 7.62mm)
Surface Mount NO
Technical
Operating Temperature -40°C~125°C
Packaging Tube
JESD-609 Code e0
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 8
Terminal Finish TIN LEAD
Voltage - Supply 12.5V~18V
Terminal Position DUAL
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Terminal Pitch 2.54mm
Reach Compliance Code unknown
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 8
JESD-30 Code R-PDIP-T8
Qualification Status COMMERCIAL
Input Voltage-Nom 15V
Analog IC - Other Type POWER FACTOR CONTROLLER
Input Voltage (Min) 9V
Output Current-Max 0.75A
Frequency - Switching 58kHz
Input Voltage (Max) 18V
Switcher Configuration BOOST
Mode Critical Conduction (CRM), Discontinuous (Transition)
Current - Startup 17μA
Dimensions
Height Seated (Max) 4.45mm
Length 9.78mm
Width 7.62mm
Compliance
RoHS Status Non-RoHS Compliant
