ML4821CP image
Favorite
ML4821CP image
Favorite
RoHS
RoHS RoHS compliant
Package 18-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / PMIC - PFC (Power Factor Correction)
Description Tube R-PDIP-T18 SINGLE Average Current power factor correction device 12V~18V 1MHz 600muA 4.32mm
PDF
/
Buying Options
Total Price: USD $2.89
Unit Price: USD $2.8918
≥1 USD $2.8918
≥10 USD $2.3731
≥100 USD $2.299
≥500 USD $2.22395
≥1000 USD $2.14985
Inventory: 1286
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Width 7.62mm
Length 22.86mm
Height Seated (Max) 4.32mm

Technical

Current - Startup 600μA
Mode Average Current
Switcher Configuration SINGLE
Control Technique PULSE WIDTH MODULATION
Input Voltage (Max) 25V
Frequency - Switching 1MHz
Output Current-Max 1A
Input Voltage (Min) 12V
Analog IC - Other Type POWER FACTOR CONTROLLER
Input Voltage-Nom 15V
Qualification Status COMMERCIAL
JESD-30 Code R-PDIP-T18
Pin Count 18
Time@Peak Reflow Temperature-Max (s) NOT APPLICABLE
Reach Compliance Code unknown
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT APPLICABLE
Terminal Position DUAL
Voltage - Supply 12V~18V
Terminal Finish MATTE TIN
Number of Terminations 18
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e3
Packaging Tube
Operating Temperature 0°C~70°C

Physical

Surface Mount NO
Package / Case 18-DIP (0.300, 7.62mm)
Mounting Type Through Hole
