ML4800CS
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - PFC (Power Factor Correction)
Description
GULL WING Surface Mount Obsolete ROHS3Compliant PFC IC Average Current 0C~70C 1.75mm 200muA 76kHz
PDF
/
Buying Options
Total Price: USD $2.02
Unit Price: USD $2.024
≥1 USD $2.024
Inventory: 3060
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3.9mm
Length 9.9mm
Height Seated (Max) 1.75mm
Technical
Current - Startup 200μA
Mode Average Current
Switcher Configuration BOOST
Control Technique PULSE WIDTH MODULATION
Input Voltage (Max) 16.5V
Frequency - Switching 76kHz
Output Current-Max 1A
Input Voltage (Min) 10.8V
Analog IC - Other Type POWER FACTOR CONTROLLER WITH POST REGULATOR
Input Voltage-Nom 15V
Qualification Status COMMERCIAL
JESD-30 Code R-PDSO-G16
Pin Count 16
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 1.27mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 11V~16.5V
Technology BICMOS
Terminal Finish TIN LEAD
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Packaging Tube
Operating Temperature 0°C~70°C
Physical
Surface Mount YES
Package / Case 16-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
