MC33232DG
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - PFC (Power Factor Correction)
Description
GULL WING Surface Mount Obsolete ROHS3Compliant PFC IC Critical Conduction (CRM) -20C~85C 1.75mm 50muA 12V~25V
PDF
/
Buying Options
Total Price: USD $14.69
Unit Price: USD $14.69175
≥1 USD $14.69175
≥10 USD $12.05455
≥100 USD $11.67835
≥500 USD $11.3012
≥1000 USD $10.925
Inventory: 9706
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Surface Mount YES
Technical
Operating Temperature -20°C~85°C
Packaging Tube
Series SMARTMOS?
JESD-609 Code e3
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 8
Terminal Finish MATTE TIN
Voltage - Supply 12V~25V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 1.27mm
Reach Compliance Code unknown
Time@Peak Reflow Temperature-Max (s) 40
Pin Count 8
JESD-30 Code R-PDSO-G8
Qualification Status COMMERCIAL
Input Voltage-Nom 12V
Analog IC - Other Type POWER FACTOR CONTROLLER
Input Voltage (Min) 12V
Output Current-Max 0.75A
Input Voltage (Max) 28V
Switcher Configuration SINGLE
Mode Critical Conduction (CRM)
Current - Startup 50μA
Dimensions
Height Seated (Max) 1.75mm
Length 4.9mm
Width 3.9mm
Compliance
RoHS Status ROHS3 Compliant
