MC33232D image
Favorite
MC33232D image
Favorite
RoHS
/
Package 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - PFC (Power Factor Correction)
Description GULL WING Surface Mount Obsolete Non-RoHS Compliant PFC IC Critical Conduction (CRM) -20C~85C 1.75mm 50muA 12V~25V
PDF
/
Inventory: 7445
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Surface Mount YES

Technical

Operating Temperature -20°C~85°C
Packaging Tube
Series SMARTMOS?
JESD-609 Code e0
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
Terminal Finish TIN LEAD
Voltage - Supply 12V~25V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Terminal Pitch 1.27mm
Reach Compliance Code unknown
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 8
JESD-30 Code R-PDSO-G8
Qualification Status COMMERCIAL
Input Voltage-Nom 12V
Analog IC - Other Type POWER FACTOR CONTROLLER
Input Voltage (Min) 12V
Output Current-Max 0.75A
Input Voltage (Max) 28V
Switcher Configuration SINGLE
Mode Critical Conduction (CRM)
Current - Startup 50μA

Dimensions

Height Seated (Max) 1.75mm
Length 4.9mm
Width 3.9mm

Compliance

RoHS Status Non-RoHS Compliant
