FAN4822IMX
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / PMIC - PFC (Power Factor Correction)
Description
GULL WING Surface Mount Obsolete ROHS3Compliant PFC IC Average Current -40C~85C 2.72mm 700muA 12.8V~14.2V
PDF
/
Buying Options
Total Price: USD $1.79
Unit Price: USD $1.7864
≥1 USD $1.7864
Inventory: 1035
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 7.52mm
Length 10.34mm
Height Seated (Max) 2.72mm
Technical
Current - Startup 700μA
Mode Average Current
Switcher Configuration SINGLE
Control Technique PULSE WIDTH MODULATION
Input Voltage (Max) 7V
Output Current-Max 0.5A
Analog IC - Other Type POWER FACTOR CONTROLLER
Qualification Status COMMERCIAL
JESD-30 Code R-PDSO-G16
Pin Count 16
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code unknown
Terminal Pitch 1.27mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 12.8V~14.2V
Terminal Finish TIN LEAD
Number of Terminations 16
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Surface Mount YES
Package / Case 16-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
