NCP1654BD65R2G
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - PFC (Power Factor Correction)
Description
Tape & Reel (TR) NCP1654 ACTIVE (Last Updated: 1day ago) e3 power factor correction device 9V~20V 65kHz 75muA 1.5mm
PDF
/
Buying Options
Total Price: USD $0.47
Unit Price: USD $0.47025
≥1 USD $0.47025
≥10 USD $0.3857
≥100 USD $0.3743
≥500 USD $0.36195
≥1000 USD $0.3496
≥3000 USD $0.3135
Inventory: 329802
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 4mm
Length 5mm
Height 1.5mm
Technical
Current - Startup 75μA
Mode Continuous Conduction (CCM)
Max Duty Cycle 97 %
Switcher Configuration BOOST
Nominal Input Voltage 20V
Control Technique PULSE WIDTH MODULATION
Halogen Free Halogen Free
Frequency - Switching 58kHz~72kHz
Output Current-Max 1.5A
Max Supply Current 6mA
Operating Supply Current 4.7mA
Analog IC - Other Type POWER FACTOR CONTROLLER
Power Supplies 15V
Input Voltage-Nom 15V
Pin Count 8
Base Part Number NCP1654
Frequency 65kHz
Terminal Pitch 1.27mm
Supply Voltage 15V
Number of Functions 1
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 9V~20V
Max Power Dissipation 450mW
Subcategory Switching Regulator or Controllers
Additional Feature CAN ALSO BE CONFIGURED IN AVERAGE CURRENT
Terminal Finish Tin (Sn)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2001
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Factory Lead Time 10 Weeks
