NCP1653PG
RoHS
/
Package 8-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / PMIC - PFC (Power Factor Correction)
Description
Tube NCP1653 LAST SHIPMENTS (Last Updated: 3days ago) e3 power factor correction device 8.75V~18V 90kHz~110kHz 30mA 3.44mm
PDF
/
Buying Options
Total Price: USD $1
Unit Price: USD $1.00045
≥1 USD $1.00045
≥10 USD $0.94382
≥100 USD $0.8904
≥500 USD $0.84
Inventory: 800
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 2 Weeks
Lifecycle Status LAST SHIPMENTS (Last Updated: 3 days ago)
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 8-DIP (0.300, 7.62mm)
Number of Pins 8
Technical
Operating Temperature -40°C~125°C
Packaging Tube
Published 2004
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Tin (Sn)
Additional Feature ALSO OPERATES IN PEAK CURRENT MODE
Subcategory Switching Regulator or Controllers
Voltage - Supply 8.75V~18V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 15V
Terminal Pitch 2.54mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number NCP1653
Pin Count 8
Number of Outputs 1
Input Voltage-Nom 15V
Analog IC - Other Type POWER FACTOR CONTROLLER
Max Supply Current 30mA
Input Voltage (Min) 9.95V
Frequency - Switching 90kHz~110kHz
Halogen Free Halogen Free
Control Technique PULSE WIDTH MODULATION
Switcher Configuration SINGLE
Max Duty Cycle 94 %
Mode Continuous Conduction (CCM)
Dimensions
Height 3.44mm
Length 10.16mm
Width 6.6mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
