MC33232DG
RoHS
/
Package 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - PFC (Power Factor Correction)
Description
Tube MC33232 SMARTMOS? e3 power factor correction device 12V~25V 50muA 1.75mm -20C~85C
PDF
/
Buying Options
Total Price: USD $14.69
Unit Price: USD $14.69175
≥1 USD $14.69175
≥10 USD $12.05455
≥100 USD $11.67835
≥500 USD $11.3012
≥1000 USD $10.925
Inventory: 1578
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Width 3.9mm
Length 4.9mm
Height Seated (Max) 1.75mm
Technical
Current - Startup 50μA
Mode Critical Conduction (CRM)
Switcher Configuration SINGLE
Supply Current-Max (Isup) 20mA
Output Current-Max 0.75A
Input Voltage (Min) 12V
Analog IC - Other Type POWER FACTOR CONTROLLER
Power Supplies 12V
Input Voltage-Nom 12V
Qualification Status Not Qualified
Pin Count 8
Base Part Number MC33232
Time@Peak Reflow Temperature-Max (s) 40
Reach Compliance Code unknown
Terminal Pitch 1.27mm
Supply Voltage 12V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 12V~25V
Subcategory Switching Regulator or Controllers
Terminal Finish Tin (Sn)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Series SMARTMOS?
Published 2007
Packaging Tube
Operating Temperature -20°C~85°C
Physical
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
