LT1248IS#PBF
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - PFC (Power Factor Correction)
Description
Tube LT1248 8542.39.00.01 SINGLE power factor correction device 15.5V~27V 300kHz 250muA 1.75mm
PDF
/
Buying Options
Total Price: USD $12.69
Unit Price: USD $12.6896
≥1 USD $12.6896
≥10 USD $11.6644
≥100 USD $11.181104
≥500 USD $9.851424
≥1000 USD $9.367952
≥3000 USD $8.763568
Inventory: 476
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3.9mm
Length 9.9mm
Height Seated (Max) 1.75mm
Technical
Current - Startup 250μA
Mode Average Current
Switcher Configuration SINGLE
Supply Current-Max (Isup) 12mA
Control Technique PULSE WIDTH MODULATION
Input Voltage (Max) 25V
Frequency - Switching 300kHz
Output Current-Max 1.5A
Input Voltage (Min) 11.5V
Analog IC - Other Type POWER FACTOR CONTROLLER
Output Voltage 7.5V
Qualification Status Not Qualified
JESD-30 Code R-PDSO-G16
Pin Count 16
Base Part Number LT1248
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 1.27mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 15.5V~27V
Technology BIPOLAR
Subcategory Switching Regulator or Controllers
HTS Code 8542.39.00.01
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 1999
Packaging Tube
Operating Temperature -40°C~125°C
Physical
Surface Mount YES
Package / Case 16-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
